Pump Selection Guide

Optional Pump Construction Chart

Pump ModelFlow (GPM)Pressure (PSI)Speed (RPM)
P205-5100 0.38 2500 1750
P205-5111 0.38 2500 1750
P205-5121 0.38 2500 1750
P205-5180 0.38 2500 1750
P201-4120 0.4 3200 1450
P201-4121 0.4 3200 1450
P201-4123 0.4 3200 1450
P201-4127 0.4 3200 1450
CP230-5123 0.45 2000 750
CP230 0.5 2000 750
CP230-NPT 0.5 2000 750
CP217-5123 0.73 2000 750
P206-5100 0.73 2000 1750
P206-5111 0.73 2000 1750
P206-5180 0.73 2000 1750
CP217-NPT 0.73 2000 750
CP217 0.73 2000 750
P206-5125 0.73 2500 1750
P206-5121 0.8 2000 1750
P205 0.8 2000 3450
P48 0.82 3000 1420
P213-4121 0.87 3190 1450
P225 0.9 2000 1750
P207-5125 0.9 2500 1750
P208-B 1.0 2000 1750
P230A-3100 1.1 2200 1750
P230A-5100 1.1 2200 1750
P230A-5111 1.1 2200 1750
P230A-5121 1.1 2200 1750
P230A-5123 1.1 2200 1750
P230 1.1 2000 1750
P230-0030 1.1 2000 1750
P47 1.2 3000 1420
P202-4120 1.27 3190 1450
P202-4121 1.27 3190 1450
P202-4127 1.27 3190 1450
P57 1.3 5000 1420
P57-0011 1.3 5000 1420
CP218 1.4 2000 750
CP218-5123 1.4 2000 750
CP218-NPT 1.4 2000 750
P209-5100 1.5 2000 1750
P209-5111 1.5 2000 1750
P209-5121 1.5 2000 1750
P209-5180 1.5 2000 1750
P206 1.5 2000 3450
P226 1.5 2000 1750
P207 1.7 2000 3450
P223 1.7 2000 1750
P49HT 1.7 870 900
P204-4120 1.8 3200 1450
P204-4121 1.8 3200 1450
P217 1.8 2000 1750
P228 1.8 2000 1750
P204-4127 1.8 3200 1450
P217A-3100 1.85 2200 1750
P217A-5111 1.85 2200 1750
P217A-5121 1.85 2200 1750
P217A-5123 1.85 2200 1750
P217A-5100 1.85 2200 1750
CP220 1.9 2000 750
CP220-5123 1.9 2000 750
CP220-NPT 1.9 2000 750
P208 1.9 2000 3450
CP460-4053 2 7250 750
P227A-3100 2.1 2000 1750
P227A-5100 2.1 2000 1750
P227A-5111 2.1 2000 1750
P227A-5121 2.1 2000 1750
P227A-5123 2.1 2000 1750
P227 2.1 2000 1750
P232 2.1 2500 1750
P221A-5100 2.3 2200 1750
P221A-5111 2.3 2200 1750
P221A-5121 2.3 2200 1750
P221A-5123 2.3 2200 1750
P221 2.3 2000 1750
P221-0030 2.3 2000 1750
P221A-3100 2.34 2200 1750
GX2525 2.5 2500 3450
GX2525A 2.5 2500 3450
P46HT 2.5 870 900
P209 2.7 2000 3450
P49W 2.7 2200 1420
P49W-HK 2.7 2200 1420
P327 2.9 3500 3450
P414 3.1 10150 1450
P480 3.2 7250 1450
P210 3.3 2000 3450
P217MT-0020 3.3 2000 3450
LP1000 3.4 15000 1000
P218A-3100 3.4 2200 1750
P218A-5100 3.4 2200 1750
P218A-5111 3.4 2200 1750
P218A-5121 3.4 2200 1750
P218A-5123 3.4 2200 1750
P218 3.4 2000 1750
P317 3.5 3045 1750
P317-0030 3.5 3045 1750
P323 3.5 3685 1750
P340 3.7 3500 1750
P211 3.8 2000 3450
P314 3.8 3500 3450
P321 3.8 3200 3450
P460A 3.8 7250 1450
P46W 3.9 2200 1420
P46W-HK 3.9 2200 1420
P55-5100 3.9 2320 1420
P55-5121 3.9 1500 1420
P316 4 3045 1450
P316-0030 4 3045 1450
P322 4 3500 1450
P54W 4 4000 1450
P328 4.1 3200 3450
P329 4.1 3500 3450
P219A-3100 4.2 2200 1750
P219A-5100 4.2 2200 1750
P219A-5111 4.2 2200 1750
P219A-5121 4.2 2200 1750
P219A-5123 4.2 2200 1750
P219 4.2 2000 1750
P219-0030 4.2 2000 1750
P219MT-0020 4.2 2000 1750
P332 4.4 3000 1450
LP800 4.6 11600 1000
P462 4.6 7250 1750
P220A-3100 4.7 2200 1750
P220A-5100 4.7 2200 1750
P220A-5111 4.7 2200 1750
P220A-5121 4.7 2200 1750
P220A-5123 4.7 2200 1750
P220 4.7 2000 1750
P220-0030 4.7 2000 1750
GP5114 4.8 17400 1000
P318 4.8 2000 1450
P319 4.8 2500 3450
P319-0030 4.8 2500 3450
P324 4.8 2200 1450
P325 4.8 3045 3450
P324-0021 4.8 2200 1450
P55W 4.9 2320 1420
P58W 5.0 3500 1450
P485 5.3 7250 1450
P485-4000 5.3 7250 1450
CP425 5.5 2000 750
CP425-5123 5.5 2030 750
GP5116 5.5 15000 850
P450 5.5 5100 1450
P450-3100 5.5 5100 1450
P455B 5.5 4350 1450
P450-5100 5.5 5075 1450
P455BH 5.5 4350 1450
P450-5121 5.5 5075 1450
P334 5.5 2000 1450
P450-5130 5.5 5075 1450
P451 5.8 5100 1725
P456B 5.8 4350 1725
BP100 5.9 1885 750
LP900 6 8700 1000
P56W 6.1 1900 1420
P56W-0011 6.1 1900 1420
P56W-0021 6.1 1900 1420
P56W-0121 6.1 1900 1420
P56HTK 6.1 1900 1420
P56W-HK 6.1 1900 1420
SP200HT 6.1 870 900
P56-5100 6.1 1900 1420
P56HT 6.2 870 750
P465 6.3 5800 1450
P465H 6.3 5800 1450
P465-4000 6.3 5800 1450
CP420 6.4 1740 750
CP420-5123 6.4 1740 750
P330 6.5 1000 3450
P435 6.6 3625 1450
P435-3100 6.6 3625 1450
P435H 6.6 3625 1450
P435-5100 6.6 3625 1450
P435-5130 6.6 3625 1450
P435-5121 6.6 3625 1450
SP351W 6.7 3190 1420
SP351W-3100 6.7 3200 1420
SP100HT 7.1 870 900
SP100HTK 7.1 870 900
P59W 7.5 1900 1450
P59MT-0020 7.5 1450 1450
P59W-0021 7.5 1900 1450
LP700 7.9 7250 1000
LP750 7.9 7250 1000
LP700-0050 7.9 7250 1000
LP700-0051 7.9 7250 1000
P423 8.2 2900 1450
P423-3100 8.2 2900 1450
P423-5100 8.2 3000 1450
P423HP 8.2 4060 1450
MP4120 8.9 3625 1450
MP4120-SWS 8.9 3625 1450
CP470 9.25 1740 750
SP200W 9.6 2175 1420
LP460 9.8 5800 1000
LP600 9.8 5800 1000
LP600-4000 9.8 5800 1000
LP600-5100 9.8 5800 1000
LP601 9.8 5800 1000
GP7122 9.9 10300 750
GP7522 9.9 10150 750
P422 9.9 2600 1450
P422-5100 9.9 2600 1450
P422H 9.9 2610 1450
P422HP 9.9 4060 1450
GP7522GB-180 9.9 10150 750
GP7522GB 9.9 10150 750
GP7522GBHS-180 9.9 10150 750
GP5120 10.5 8700 1000
MP4130HTC 10.5 1160 750
P425-3100 10.6 2465 1450
LP650 10.6 6000 1080
LP605 10.6 6090 1100
P425 10.7 2465 1450
P425-5100 10.7 2500 1450
P425-5111 10.7 2500 1450
P425-5121 10.7 2500 1450
P425HP 10.7 3045 1450
SP100HK 11.2 1885 1420
SP100W 11.2 1885 1420
SP100W-0011 11.2 2000 1420
SP100W-3100 11.2 1880 1420
GP5122 11.9 7250 930
LP470 12.2 4640 1000
MP4126HTC 12.2 1160 750
MP4135HT 12.2 1160 750
MP4135HTC 12.2 1160 750
GP7622 12.7 15000 800
GP6124-4000 12.8 6090 800
GP7124A-4000 12.8 7400 750
MP4124 12.8 2610 1450
P420A 12.8 2175 1450
P420A-0021 12.8 2175 1450
P420A-3100 12.8 2175 1450
P420A-5100 12.8 2200 1450
P420A-5111 12.8 2200 1450
P420A-5121 12.8 2200 1450
MP4124-SWS 12.8 2610 1450
P420CR-0020 12.8 2175 1450
P420H 12.8 2175 1450
P420A-0011 12.8 2175 1450
P420HP 13 3045 1450
GP5124 13.2 5800 850
MP4135 13.5 1885 1100
LP301A 14.2 4000 1000
LP301A-4000 14.2 4000 1000
LP301A-SSP 14.2 4000 1000
LP301A-0056 14.2 4000 1000
LP301A-0081 14.2 4000 1000
LP301A-5100 14.2 3900 1000
LP301AGB-180 14.2 4000 1000
LP301AGBHS 14.2 4000 1000
P426HP 14.3 3000 1450
P426HHP 14.3 3000 1450
LP400 15.1 3600 1000
MP4130 15.4 1600 1100
MP4130HK 15.4 1600 1100
MP4130-3100 15.4 1600 1100
MP4130-5100 15.4 1600 1100
P490 15.7 2000 1450
P490-7000 15.7 2000 1450
P490A 15.7 2000 1450
CLP121A 15.9 1740 500
LP305 15.9 4060 1100
CLP121AGB-5123 15.9 1740 500
LP121-4000HT 17.7 1160 570
LP121-4000HTC 17.7 1160 570
LP121HT 17.7 1160 570
LP121HTC 17.7 1160 570
LP121-5100HT 17.7 1160 570
LP121-5100HTC 17.7 1160 570
GP7128 17.9 5800 750
MP4126 17.9 1600 1100
MP4135-3100 17.9 1600 1100
MP4126-5100 17.9 1600 1100
GP7128-0021 17.9 5800 750
GP7128-4100 17.9 5945 750
GP6128 18 4350 800
P470-7000 18.4 2000 1450
P470H 18.4 2030 1450
P470H-7000 18.4 2030 1450
P470A 18.4 2000 1450
BP5236 18.5 1500 570
LP200 19 2900 1000
LP200-SS 19 3000 1000
LP200GB-SS-180 19 3000 1000
LP200GBHS-SS 19.0 3000 1000
LP200GBHS-5100-SS 19.0 3000 1000
LP200-5100 19.1 3000 1000
LP450 19.7 2600 1000
GP5128 20.6 4060 1000
GP5128GBHS 20.6 4060 1000
GP5124-28 20.6 4060 1400
GP5128GB Series 20.6 4060 1000
GP5128-BSP 20.6 4060 1000
GP5128-SSP 20.6 4060 1000
GP5128HS 21.0 4060 1000
LP350 22.6 2300 1000
P533 22.7 2175 1450
GP7132 23.4 4350 750
GP7532GB 23.4 4350 750
GP6132 23.5 3045 800
GP6132-4000 23.5 3045 800
P532 24.4 2175 1450
LP121 24.8 1600 800
GP7142-4000HTC 25.1 1160 460
GP7142HTC 25.1 1160 460
LP250-3100 25.7 2030 1000
LP255 25.7 2175 1000
LP250 26 2200 1000
LP250-5100 26 2200 1000
LP250W-MT 26 2200 1000
LP250MT-0020 26 2200 1000
P536 26.4 1740 1450
GP5132GB-180 27.2 3000 1000
GP5132 27.7 2900 1000
GP5132HS 27.7 2900 1000
GP5132-SSP 27.7 2900 1000
GP5132-5100 27.7 2900 1000
GP5132GBHS 27.7 3000 1000
GP5132GBHS-5100 27.7 3000 1000
GP7136 28.3 3625 700
GP7136-4000 28.3 3625 700
GP8035 29.1 7250 580
GP8135 29.1 7250 580
GP8135A 29.1 7250 580
GP8035A 29.1 7250 580
LP121A 32.5 1740 1000
LP121A-0011 32.5 1740 1000
LP121A-5100 32.5 1740 1000
LP121A-5121 32.5 1740 1000
LP121A-5123 32.5 1740 1000
GP5136 33.8 2320 910
GP5136-HS 33.8 2320 910
GP5136-5100 33.8 2320 910
GP5136GB 33.8 2320 910
GP5136GBHS 33.8 2320 910
LP122A 35.4 1300 800
LP123 35.4 1300 800
LP122A-4000 35.4 1300 800
LP122A-5100 35.4 1300 800
P540 35.4 1450 1450
P541 35.4 1450 1450
LP122B 35.4 1300 800
LP122A-3100 35.6 1300 800
GP7636GB 36.4 3800 900
GP6140-4000 36.7 2175 800
GP6140 36.7 2175 800
GP7142 38.4 2755 700
GP7142-4000 38.4 2610 700
GP7142-5100 38.4 2600 700
GP7142-5121 38.4 2600 700
GP7242 38.4 2755 700
GP8040 39.6 5510 580
GP8140 39.6 5510 580
GP8140A 39.6 5510 580
GP8040 39.6 5500 580
GP8040A 39.6 5500 580
GP5142 40.4 1885 800
GP5142GBHS 40.4 1885 800
BP6150 42.3 1500 600
GP7155HTC 42.4 1160 460
GP7255HTC 42.4 1160 460
GP7155-4000HTC 42.4 1160 460
GP5145 43.5 1450 750
GP5145-5100 43.5 1500 750
GP5145-HS 43.5 1450 750
GP5145GBHS 43.5 1450 750
GP5145LS 45 1500 800
GP6145 46.5 1740 800
GP6145-3100 46.5 1740 800
GP6145-4000 46.5 1740 800
GP6145 46.5 1740 800
GP7145 47.5 3000 750
GP7145-SSP 47.5 3000 750
GP7145-5000 47.5 3000 750
GP8045 48.9 4350 580
GP8045-3100 48.9 4350 580
GP8045-5100 48.9 4350 580
GP8045A 48.9 3170 580
GP8145 49 4350 580
CGP7555-1023 51.5 1500 550
GP7150A 54.4 1900 700
GP7150-5100 54.4 1900 700
GP7150-4000 54.5 1900 700
GP7645 55.5 3000 800
GP7645GB 55.5 3000 800
GP7645GB-180 55.5 3000 800
GP7645GBHS 55.5 3000 800
GP7645GBHS-180 55.5 3000 800
GP7545GB 55.5 3000 900
GP7545GBHS 55.5 3000 900
GP8148 56 3770 580
GP7545GB-180 56.0 2900 900
GP8048 56.3 3770 580
GP8048-3100 56.3 3770 580
GP8048-5100 56.3 3770 580
GP8048A 56.3 2775 580
GP7155A 65.8 1500 700
GP7155-3100 65.8 1500 700
GP7155-4000 65.8 1500 700
GP7155-5100 65.8 1500 700
GP7255A 65.8 1500 700
GP7255A-SSP 65.8 1500 700
GP7255A-5000 65.8 1500 700
GP8040-5100 69.6 5510 580
GP7650 69.7 2500 800
GP7650GB 70 2540 800
GP7650GBHS 70 2540 800
GP7650GBHS-180 70 2540 800
GP7550GB 70 2540 900
GP7550GBHS 70 2540 900
GP8055-3100 74.8 3000 580
GP8055-5100 74.8 3000 580
GP8055 75.3 3000 580
GP8055-1000 75.3 3000 580
GP8155 75.3 3000 580
GP8155GB-180 75.3 3000 580
GP8055-Brine 75.3 3000 580
GP8155GBHS 75.3 3000 580
GP8155GBHS-1000 75.3 3000 580
GP8065HT-1000 75.3 1500 420
GP8055A 75.3 2000 580
GP8055A-1000 75.3 2000 580
GP8155-1000 75.5 3000 580
BP7170 84.5 1015 560
GP7170-4000 84.5 1450 700
GP7655 84.5 2000 800
GP7655GB 84.5 2000 800
GP7655GBHS-180 84.5 2000 800
GP7655GBHS 84.5 2000 800
GP7655GB-180 84.5 2000 800
GP7555GB 84.5 2000 900
GP7555GBHS 84.5 2000 900
GP7555GB-180 84.5 2030 900
GP8060-Brine 89 2465 580
GP8060 90 2465 580
GP8060-1000 90 2465 580
GP8160 90 2500 580
GP8160-1000 90 2500 580
GP8160GB-180 90 2500 580
GP8060-3100 90 2465 580
GP8060-5100 90 2465 580
GP8160GBHS 90 2500 580
GP8160GBHS-1000 90 2500 580
GP8060A 90 1730 580
GP8060A-1000 90 1730 580
GP8065-3100 105 2030 580
GP8065-5100 105 2030 580
GP8165 105.6 2000 580
GP8165-1000 105.6 2000 580
BP7171 105.7 1015 700
GP8065 105.7 2000 580
GP8065-1000 105.7 2000 580
GP8165GB-180 105.7 2000 580
GP8065-Brine 105.7 2000 580
GP8065A 105.7 1500 580
GP8065A-1000 105.7 1500 580
GP8165GBHS 106 2000 580
GP8165GBHS-1000 106 2000 580
GP8065-5100 106 2000 580
GP8265 127 1740 700
GP8265GB-1000 127 1740 700
BP8076 132 1500 520
BP8176 132 1500 520
GP8076 132 1500 520
GP8176 132 1500 520
GP8076A 132 1500 520
BP8085 171.7 1160 530
back to top
