A German-made triplex plunger positive displacement pump with reciprocating plungers for direct or belt drive applications.
Anodized aluminum crankcase with sight glass and vented dipstick; forged, through-hardened, ground and polished crankshaft; bronze connecting rods; hardened stainless steel plunger bases; solid ceramic plungers; nitrile seals (with fabric reinforcing); stainless steel valves and 316 stainless steel manifold.
Gearbox and bell housings (to connect to gasoline, diesel, electric or hydraulic drive).
WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
|Flow||12.8 GPM||48.4 L/min|
|Maximum Discharge Pressure||2175 PSI||150 bar|
|Crankshaft Speed||1450 RPM|
|Power||19.2 HP||14.3 KW|
|Max Temperature||160 °F||70 °C|
|Inlet Port Size||(2) 1" BSP|
|Discharge Port Size||(2) 3/4" BSP|
|Plunger Diameter||0.98 in.||25 mm|
|Stroke||0.98 in.||24 mm|
|Maximum Inlet Pressure||145 PSI||10 bar|
|Crankshaft Diameter||1.1 in.||28 mm|
|Crankshaft Rotation||Top of Pulley Towards Manifold|
|Key Width||0.31 in.||8 mm|
|Crankshaft Mounting||Either Side|
|Crankcase Oil Capacity||27 fl. oz.||0.8 L|
|Weight||36.6 lbs.||16.6 kg|
|RPM||GPM||1000 PSI||1500 PSI||1700 PSI||2175 PSI|
