A German-made reciprocating triplex plunger pump.
Spheroidal cast iron crankcase with sight glass and vented dipstick; forged, through-hardened, ground and polished crankshaft; bronze connecting rods; hardened stainless steel plunger bases; solid ceramic plungers; nitrile seals with fabric reinforcing; stainless steel valves and cast aluminum bronze manifold.
WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
|Flow||65.8 GPM||250 L/min|
|Maximum Discharge Pressure||1500 PSI||207 bar|
|Crankshaft Speed||700 RPM|
|Maximum Inlet Pressure||145 PSI||10 bar|
|Maximum Temperature||140 °F||60 °C|
|Plunger Diameter||2.17″||55 mm|
|Crankshaft Diameter||48 mm|
|Crankshaft Rotation||Top of Pulley Towards Manifold|
|Key Width||0.6″||14 mm|
|Crankshaft Mounting||Either Side|
|Inlet Ports||(2) 2-1/2″ NPT|
|Discharge Ports||(2) 1-1/4″ NPT|
|Crankcase Capacity||1.6 gal||6.0 L|
|Weight||455 lbs.||206 kg|
|Key Component Material|
|Plunger||Solid Ceramic Oxide|
|Seals||Nitrile with Fabric Reinforcing|
|Gear End||Spheroidal Cast Iron|
|RPM||GPM||800 PSI||1000 PSI||1300 PSI||1500 PSI|
The ratings shown are the power requirements for the pump. Gas engine power outputs must be approximately twice the pump power requirements shown above.
We recommend a 1.15 service factor be specified when selecting an electric motor as the power source. To compute specific pump horsepower requirements use the following formulas:
Electric HP = (GPM X PSI)/1450
Gas HP = (GPM X PSI)/1100
*Engine power varies based on horizontal or vertical orientation, as well as by makes and models from each manufacturer.
|Plunger Packing Kit – Part #9220|
|Valve Assembly Kit – Part #09614|
|51B||08282||Valve Spring Guide||1|
|Oil Seal Kit – Part #09221|
|32||07624||Radial Shaft Seal||3|
Repair Kits Available
The repair kits listed to the right are available for this pump. If you need further information about these repair kits, or have questions about other specific parts for your pump, please contact you local Giant distributor or contact Giant customer service.
