P425-BSP
WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| Specification | US | Metric |
|---|---|---|
| Flow | 10.7 GPM | 40.4 L/min |
| Maximum Discharge Pressure | 2465 PSI | 170 bar |
| Crankshaft Speed | 1450 RPM | |
| Power | 18.1 HP | 13.5 KW |
| Max Temperature | 160 °F | 70 °C |
| Inlet Port Size | (2) 1" BSP | |
| Discharge Port Size | (2) 3/4" BSP | |
| Plunger Diameter | 0.98 in. | 25 mm |
| Stroke | 0.79 in. | 20 mm |
| Maximum Inlet Pressure | 145 PSI | 10 bar |
| Crankshaft Diameter | 1.102 in. | 28 mm |
| Crankshaft Rotation | Top of Pulley Towards Manifold | |
| Key Width | 0.315 in. | 8 mm |
| Crankshaft Mounting | Either Side | |
| Crankcase Oil Capacity US | 30.4 fl. oz. | 0.9 L |
| Weight | 38.3 lbs. | 17.4 kg |
| NPSHR | 26.2 Ft.-head | 8.0 mWs |
The repair kits listed below are available for this pump. If you need further information about these repair kits, or have questions about other specific parts for your pump, please contact you local Giant distributor or contact Giant customer service.
| ITEM# | PART# | DESCRIPTION | Qty. |
|---|---|---|---|
| Plunger Packing Kit – Part #09140 | |||
| 21 | 07266 | O-Ring | 3 |
| 23 | 12254 | V-Sleeve | 3 |
| 23B | 12255 | Weep Seal | 3 |
| 24 | 08376 | Pressure Ring | 6 |
| Valve Assembly Kit – Part #09143 | |||
| 27A | 08408 | Valve Assembly, Complete | 6 |
| 33 | 07214 | O-Ring | 6 |
| Oil Seal Kit – Part #09641 | |||
| 19 | 05444 | Oil Seal | 3 |
Horsepower Specifications
| RPM | GPM | 1000 PSI | 1500 PSI | 2000 PSI | 2465 PSI |
|---|---|---|---|---|---|
| 750 | 5.6 | 3.8 | 5.7 | 7.6 | 9.4 |
| 900 | 6.7 | 4.6 | 6.9 | 9.1 | 11.3 |
| 1010 | 7.5 | 5.2 | 7.7 | 10.2 | 12.7 |
| 1120 | 8.3 | 5.7 | 8.6 | 11.4 | 14.1 |
| 1240 | 9.2 | 6.3 | 9.5 | 12.6 | 15.6 |
| 1450 | 10.7 | 7.4 | 11.1 | 14.7 | 18.2 |
