• Flow rate based on 100% volumetric efficiency and 68 ºF (20 ºC) ambient temperature
  • Gear with splash lubrication
  • Cycle-stress-free pumphead in stainless steel
  • Tungsten carbide plunger and valve parts in stainless steel

WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

  • K108A Literature

Sorry, there are no accessories associated with this product.

  • K108A Literature
  • K108A Performance Data


Flow (Maximum) 1.06 GPM 4.0. L/min
Inlet Pressure 58-116 PSI 4-8 bar
Pressure (Maximum) 29,000 PSI 2000 bar
Power (Maximum) 20.1 hp 15 kW
Maximum Temperature 104 ºF 40 ºC
Crankcase Oil Capacity 27 fl. oz. 0.8 L
Maximum Viscosity 1000 mPas
Noise Level 75 db
Weight 55 lbs. 25 kg

Additional Specifications are available by clicking on the thumbnail below

download spec sheet

Click the image to enlarge

Service & Repair

Giant provides service on each pump and accessory that we sell. Many basic repair procedures are covered in the Giant repair manual. For all other questions on service or repair needs please contact your local Giant distributor.
